iron ore separation machine from China manufacturer - Maanshan Baiyun Environment Protection Equipment Co.,Ltd

Payment Terms:	T/T,L/C
Place of Origin:	Anhui, China (Mainland)

Product Detail

Model No.: MAS Baiyun-CTL

Production Capacity: 100 set/ month

Delivery Date: negotiable

Means of Transport: Ocean

Packing: standard export packing

It is a developed new separating way for dry powder magnetic minerals, such as iron ore, iron sand and mill scales etc. It can be widely in metallur

Applications

Used for pre-concentration of low-grade ores ,reject waste ore, and reduce ore dressing costs;

Used for purification operation for concentrates of magnetic separation plants, increase concentrate grade;

Use for separation for iron sand efficiently.

Used for recycling ferrous metals from steel works, such as steel slag, mill scales etc;

Used for removing the ferrous contamination which has an obvious effect out of non-magnetic materials;

Main Dimension and Technical Data

Models	CTL0609	CTL0612	CTL-0618	CTL-0812	CTL-0815	CTL-0818	CTL-0821	CTL0824	CTL0918	CTL1030
Drum Spec diameter*length(mm)	600×900	600×1200	600×1800	750×1200	750×1500	750×1800	750×2100	750x2400	900x1800	900×3000
Magnetic Intensity(mT)	>120	>120	>120	>120	>120	>120	>120	>120	>120	>120
Upper limit of particle size of ore(mm)	7-0	7-0	7-0	7-0	7-0	7-0	10-0	10-0	10-0	10-0
Capacity(t/h)	5-10	10-15	15-20	20-25	30-35	40-45	60-65	80-85	90-110	150-200
External Dimensions (mm)	2320 ×1020 ×1450	2620 ×1020 ×1450	3320 x1020 x1450	2880 ×1420 ×1680	3220 ×1420 ×1680	3480 ×1420 ×1680	3780 ×1420 ×1680	4080 ×1420 ×1680	3800x 1600x 2050	5700x 1600x 2050
Overall weight of plant(ton)	1.8	2.0	2.5	3	3.6	4.2	4.5	4.8	4.6	6.5
Driving power of motor(kw)	5.5	5.5	7.5	7.5	11	11	11	11	11	11
