Product Detail

Model No.: MAS Baiyun-CTB

Production Capacity: 100 set/ month

Delivery Date: negotiable

Means of Transport: Ocean

Packing: standard export packing

MAS Baiyun CTB Wet Drum Separator is newly developed iron ore concentrating equipment under wet conditions.It has been designed by engineers having a

Applications

Used for the first stage rough concentration in the ore dressing plants. Increase recovery and reduce the load of the second-stage grinding by rejecting waste minerals.

Used for separation of iron sand under wet conditions, reject excess silica ,mud and other low-magnetic minerals, increase the grade efficiently.

Used for concentrating next stage, increase concentrate grade and recovery rate;

Used before strong magnetic operation, remove iron magnetic minerals and prevent magnetic block;

Used for recovery of iron ore in coal dressing plant.

Main Dimension and Technical Data

Model	Drum Spec (mm)	Magnetic induction intensity of drum surface(mT)			Feed density(%)	Working Space (mm)	Feed Size (mm)			Handling Capacity		Power (kw)	External Dimension (mm)	Overall weight (kg)
		Ferrite	Rear Earth				CTS	CTN	CTB	Dry Ore (t/h)	Ore Pulp (m³/h)
		Ferrite	Mean	Enha ncing			CTS	CTN	CTB	Dry Ore (t/h)	Ore Pulp (m³/h)
CTB7518	750×1800	160	170	240	20-30	35-55	6-0	3-0	1-0	35-50	110-160	3	3200×1100×1500	2450
CTB1018	1050×1800	≥180	≥190	≥300	25-35	45-65	6-0	3-0	1-0	50-90	140-205	4	3450×1650×1750	4100
CTB1021	1050×2100	≥180	≥190	≥300	25-35	45-65	6-0	3-0	1-0	55-105	160-240	4	3750×1650×1750	4550
CTB1024	1050×2400	≥180	≥190	≥300	25-35	45-65	6-0	3-0	1-0	65-120	185-270	5.5	4050×1650×1750	5070
CTB1030	1050×3000	≥180	≥190	≥300	25-35	45-65	6-0	3-0	1-0	80-150	230-340	5.5	4650×1650×1750	6560
CTB1230	1200×3000	≥180	≥190	≥300	25-35	45-65	6-0	3-0	1-0	88-165	250-370	7.5	4800×1900×1980	7500
