recycling from China manufacturer - Maanshan Baiyun Environment Protection Equipment Co.,Ltd

recycling

Payment Terms:	T/T,L/C
Place of Origin:	Anhui, China (Mainland)

Product Detail

Model No.: MAS Baiyun-RCYQ

Production Capacity: 100 set/ month

Delivery Date: negotiable

Means of Transport: Ocean

Packing: standard export packing

RCYQ Light-duty Crossbelt Magnetic Separator is developed on the basis of RCYC. It is light and handly and suitable for samller.

Features

A deep penetrating magnetic field.

Low maintenance and easy to install and operate.

Self cleaning, no manual cleaning

Small Volume, low noise,low weight, compact and simple structure

Suitable for the fields such as environment protection,food,molding,mining,etc,especially fro recycling

Main Dimensions and Technical Data

Model	Apply with belt width (mm)	Apply with belt speed (m/s)	Rated Height (mm)	Rated height magnetic induction(mT)	Iron absorption capacity (kg)	Working	Motor Power (kw)	Major Size(mm)						Weight (kg)
Model	Apply with belt width (mm)	Apply with belt speed (m/s)	Rated Height (mm)	Rated height magnetic induction(mT)	Iron absorption capacity (kg)	Working	Motor Power (kw)	A	B	C	D	E	F	Weight (kg)
RCYQ40	400	≥2.0	100	≥40	0.1-5	Continuous	0.75	1270	840	540	1050	580	270	380
RCYQ 50	500	≥2.5	150	≥50		Continuous	0.75	1322	1006	615	622	672	270	490
RCYQ 65	650	≥2.5	200	≥50		Continuous	1.1	1545	1150	710	1300	830	270	640
RCYQ 80	800	≥3.15	250	≥60	0.1-10	Continuous	1.5	1712	1385	735	972	1022	270	850
RCYQ 100	1000	≥4.0	300	≥60	0.1-10	Continuous	2.2	1882	1535	735	1122	1112	270	1300
